So what's with mast rake?
 Post Reply Post Reply Page  123 4>
Author
  Share Topic Share Topic  Topic Search Topic Search  Topic Options Topic Options
ellistine View Drop Down
Really should get out more
Really should get out more
Avatar

Joined: 06 Mar 08
Online Status: Offline
Posts: 762 		Post Options Post Options   Quote ellistine Quote  Post ReplyReply Direct Link To This Post Topic: So what's with mast rake?
    Posted: 24 Oct 10 at 9:19pm
It's one of those things that I've just accepted. The tuning guide says we should have a more upright mast in the light conditions and a more raked back mast when it's windy. I can see why an upright mast might help in the lighter conditions but what's the thinking behind raking the mast back when it's windy? What are we trying to achieve?

All I know is today our mast was raked back further than it's ever been (partly from stepping the mast in a hurry and not rechecking the pins) and with the wind in the upper teens we were stonking along. Properly planing up wind and even won the race both on the water and on corrected and that's never happened!
Back to Top
G.R.F. View Drop Down
Really should get out more
Really should get out more


Joined: 10 Aug 08
Location: United Kingdom
Online Status: Offline
Posts: 4028 		Post Options Post Options   Quote G.R.F. Quote  Post ReplyReply Direct Link To This Post Posted: 24 Oct 10 at 9:42pm
Well I think its probably the same reason as in windsurfing, which is that in increasing wind, the centre of effort of the sail moves aft so raking the rig back re-addresses the balance over the Centre of Lateral resistance, it also depowers the rig a tad.

With boats that can retract their centreboard, that is also  a reason to rake the rig back.

Also in strong wind the sail isn't always sheeted in as far, so the entire rig isn't in play, raking it back keeps the c of e over c of lr balanced, probably more important on single handers.
https://www.ease-distribution.com/
Back to Top
JimC View Drop Down
Really should get out more
Really should get out more
Avatar

Joined: 17 May 04
Location: United Kingdom
Online Status: Offline
Posts: 6661 		Post Options Post Options   Quote JimC Quote  Post ReplyReply Direct Link To This Post Posted: 24 Oct 10 at 11:17pm
To be quite honest the more I think about it the less I understand it... There are all sorts of things going on on a conventional dinghy from jib sheeting angle to the effect of the spreaders. I have a hunch that CLR is the least of it, but could easily be wrong.
Back to Top
blueboy View Drop Down
Really should get out more
Really should get out more


Joined: 27 Aug 10
Online Status: Offline
Posts: 512 		Post Options Post Options   Quote blueboy Quote  Post ReplyReply Direct Link To This Post Posted: 25 Oct 10 at 6:14am
Originally posted by JimC

To be quite honest the more I think about it the less I understand it...


Yep. I've never read a convincing explanation as to why raking a rig depowers it. All I know is that it works.
Back to Top
blueboy View Drop Down
Really should get out more
Really should get out more


Joined: 27 Aug 10
Online Status: Offline
Posts: 512 		Post Options Post Options   Quote blueboy Quote  Post ReplyReply Direct Link To This Post Posted: 25 Oct 10 at 6:19am
Originally posted by G.R.F.

Well I think its probably the same reason as in windsurfing, which is that in increasing wind, the centre of effort of the sail moves aft so raking the rig back re-addresses the balance over the Centre of Lateral resistance, it also depowers the rig a tad.

With boats that can retract their centreboard, that is also  a reason to rake the rig back.


The trouble with that theory is that keelboats also increase rake in stronger breeze. Also Merlins, for example, rake the rig long before they start raising the board.

Also in strong wind the sail isn't always sheeted in as far, so the entire rig isn't in play, raking it back keeps the c of e over c of lr balanced, probably more important on single handers.


That's 100% the wrong way around. If you ease the main-sheet, the luff depowers earlier than the leech. Therefore CoE moves back, so to restore balance you'd decrease rake, not increase it.
Back to Top
Fearfull View Drop Down
Newbie
Newbie


Joined: 20 Mar 09
Location: United Kingdom
Online Status: Offline
Posts: 11 		Post Options Post Options   Quote Fearfull Quote  Post ReplyReply Direct Link To This Post Posted: 25 Oct 10 at 4:44pm
I have always thought there are two main reasons why I rake:
1. Center of effort of the sail moves forward as breeze increases, especially as the leech is doing less and less, so I rake to move this back to where it was.
2. As I rake the angle the shrouds are at makes the mast bend more. This is more noticable in rigs with raked spreaders.

3. Less tendancy to nose dive!

Third is a bonus reason.
Back to Top
lynn1221 View Drop Down
Newbie
Newbie


Joined: 26 Oct 10
Location: US
Online Status: Offline
Posts: 1 		Post Options Post Options   Quote lynn1221 Quote  Post ReplyReply Direct Link To This Post Posted: 26 Oct 10 at 10:34am
All I know is today our mast was raked back further than it's ever been (partly from stepping the mast in a hurry and not rechecking the pins) and with the wind in the upper teens we were stonking along. Properly planing up wind and even won the race both on the water and on corrected and that's never happened!
Back to Top
tgruitt View Drop Down
Really should get out more
Really should get out more
Avatar

Joined: 02 Dec 04
Online Status: Offline
Posts: 2479 		Post Options Post Options   Quote tgruitt Quote  Post ReplyReply Direct Link To This Post Posted: 26 Oct 10 at 11:08am


RAKE!
Needs to sail more...
Back to Top
ifoxwell View Drop Down
Really should get out more
Really should get out more
Avatar

Joined: 05 Jan 06
Location: Hoo
Online Status: Offline
Posts: 669 		Post Options Post Options   Quote ifoxwell Quote  Post ReplyReply Direct Link To This Post Posted: 26 Oct 10 at 11:24am
Originally posted by JimC

To be quite honest the more I think about it the less I understand it... There are all sorts of things going on on a conventional dinghy from jib sheeting angle to the effect of the spreaders. I have a hunch that CLR is the least of it, but could easily be wrong.

I tend to agree I've always thought that the most significant factor is that raking the rig lets it all breath better, jib slot opens up, spreaders let the mast bend more etc etc.

The flaw in this theory however is that raking still works for a single sail, unstayed rig... so basically what i'm saying is that I don't have a clue either!

Ian
RS300
Back to Top
blueboy View Drop Down
Really should get out more
Really should get out more


Joined: 27 Aug 10
Online Status: Offline
Posts: 512 		Post Options Post Options   Quote blueboy Quote  Post ReplyReply Direct Link To This Post Posted: 26 Oct 10 at 12:52pm
Originally posted by Fearfull

I have always thought there are two main reasons why I rake:
1. Center of effort of the sail moves forward as breeze increases, especially as the leech is doing less and less, so I rake to move this back to where it was.


But the leech doesn't do (relatively) less. The luff does less as you either feather (jib) or ease the mainsheet while vang-sheeting.

2. As I rake the angle the shrouds are at makes the mast bend more. This is more noticable in rigs with raked spreaders.[/QUOTE]

But plenty of boats can adjust bend separately from rake e.g. with lowers, ram or backstay. Yet they all rake to depower as well as increasing mast bend.

I don't have an alternative explanation to put forward and I know rake works. I just don't buy these explanations.
Back to Top
