Tell tales: where and why |
Post Reply
|
Page 12> |
| Author |
 Share Topic Printable Version Delicious Digg Facebook Furl Google MySpace Newsvine reddit StumbleUpon Translate Twitter Windows Live Yahoo Bookmarks Topic Search  Topic Options
|
Presuming Ed
Really should get out more
Joined: 26 Feb 05 Location: United Kingdom Online Status: Offline Posts: 641 |
 Post Options
 Quote Reply
 Topic: Tell tales: where and whyPosted: 10 Apr 19 at 5:27pm |
|
Rows of telltails on a jib luff are also known as Gentry tufts. Invented by aeronautical engineer Arvel Gentry.
|
|
 |
|
|
iGRF
Really should get out more
Joined: 07 Mar 11 Location: Hythe Online Status: Offline Posts: 6499 |
Post Options
Quote Reply
Posted: 10 Apr 19 at 4:25pm |
|
Try this.. Watch them then apply more kicker.. Then sheet out a bit
You can spend too much time vacillating about things like this , just because the tel tales are working doesn't mean you're sailing fast or pointing high enough imv. |
|
|
|
|
CT249
Far too distracted from work
Joined: 08 Jul 06 Online Status: Offline Posts: 399 |
Post Options
Quote Reply
Posted: 10 Apr 19 at 11:44am |
Yep, they don't work on windsurfers. They DO work on boats, which is why guys like pro sailmakers use them.
|
|
|
|
|
JimC
Really should get out more
Joined: 17 May 04 Location: United Kingdom Online Status: Offline Posts: 6662 |
Post Options
Quote Reply
Posted: 10 Apr 19 at 7:45am |
|
I use the in line telltales for high and low mode upwind. I think a telltale about two thirds back on the main is useful to see if you're oversheeting offwind.
Edited by JimC - 10 Apr 19 at 7:47am |
|
|
|
|
Guests
Guest Group
|
Post Options
Quote Reply
Posted: 10 Apr 19 at 7:35am |
|
Thanks. That last video especially was very good.
The newer 200 sails being see through you can see a lot more of the slot and jib leech tell tale than before and I've found that very interesting. So we've gone an stuck one in a similar place on the 800. I've always used the three sets on the jib to gauge twist, but it's interesting in that video that the middle set tells you about sag. Obvious in hindsight but not something I've thought of before. I use the leech tell tales in the top corner a lot on the 200 and 800 up to max hike / flat wiring. What's hard to tell in the 800 is sheeting on the main downwind as theirs so little load in the sheet. I've seen quite a few skiffs with lots of tell tales on the main and I wonder if that's related? Also, quite a few have several sets in line on jib on the 49er and 18s / 14s too. How should these be used?   |
|
|
|
|
Eisvogel
Posting king
Joined: 09 Dec 16 Location: Birmingham Online Status: Offline Posts: 135 |
Post Options
Quote Reply
Posted: 09 Apr 19 at 5:06pm |
|
This is for an NS14, so I don't know how applicable it is to other classes, but I find the explanation very clear:
|
|
|
Enterprise 20361 (Eisvogel), Laser 102727 (Halcyon), Laser 121986
|
|
|
|
|
Steve411
Really should get out more
Joined: 09 Sep 08 Location: Cheddar, Somerset, England Online Status: Offline Posts: 705 |
Post Options
Quote Reply
Posted: 09 Apr 19 at 12:54pm |
|
The main thing is not to place them close to a seam or they will get caught. Also spray the telltale and surrounding area with silicon spray to prevent them sticking when wet.
|
|
|
|
|
iGRF
Really should get out more
Joined: 07 Mar 11 Location: Hythe Online Status: Offline Posts: 6499 |
Post Options
Quote Reply
Posted: 09 Apr 19 at 12:19pm |
|
Found them really deceptive and disconcerting, when you set them so they look as they should according to all the manuals, you go really slow. (tried them years ago on a sailboard rig) never look at them these days, use the force, it's much more reliable.
Edited by iGRF - 09 Apr 19 at 12:34pm |
|
|
|
|
Fatboi
Posting king
Joined: 09 Aug 16 Location: Hampshire Online Status: Offline Posts: 189 |
Post Options
Quote Reply
Posted: 09 Apr 19 at 12:13pm |
|
Something written by Steve Cockerill I remember reading a while ago |
|
|
|
|
bustinben
Far too distracted from work
Joined: 15 Oct 06 Online Status: Offline Posts: 288 |
Post Options
Quote Reply
Posted: 09 Apr 19 at 10:49am |
|
I stuck telltales all over my Laser sail to see what was going on.
What I discovered was so disconcerting that I quickly took them all off again! Flow is reversed in the back quarter of the sail on the leeward side in sub 8 knots  It also showed me what the furthest forward point you can stick them is. My rule of thumb is as far forward as possible, but far back enough to avoid the turbulent flow caused by the mast. I've got one that is right on the edge of disturbed area, so in some wind strengths it never flies and for when that's happening I've got one a little bit further back. I also stick one in a similar position at the top of the rig for setting the kicker on reaches in up to overpowered conditions. It lets you know if the top of the rig is too loose and you need to pull some kicker on.
Edited by bustinben - 09 Apr 19 at 10:51am |
|
|
|
|
