Does anyone know what grade of aluminium you need for masts/booms etc ?
Round type similar to Laser.
Back to Top
JimC View Drop Down
Really should get out more
Really should get out more
Avatar

Joined: 17 May 04
Location: United Kingdom
Online Status: Offline
Posts: 5978
Post Options Post Options   Quote JimC Quote  Post ReplyReply Direct Link To This Post Posted: 18 Sep 18 at 8:57pm
I believe its specially heat treated, I'm not sure its a standard grade. I have used standard grade alloy for a boom when I was broke though, I used 4 inch and cut lots of holes in the less stressed areas for weight and it lasted for years.



The holes are mostly behind the sleeve for the mainsheet, but you get the idea...

Edited by JimC - 18 Sep 18 at 9:04pm
Back to Top
423zero View Drop Down
Really should get out more
Really should get out more


Joined: 08 Jan 15
Location: United Kingdom
Online Status: Offline
Posts: 1541
Post Options Post Options   Quote 423zero Quote  Post ReplyReply Direct Link To This Post Posted: 18 Sep 18 at 9:50pm
I am attempting to set up a supply chain for Minisail owners, contact I have for Aluminium wanted to know what grade, he can get different grades, though he has just supplied what he had in stock and had no complaints.
Back to Top
Riv View Drop Down
Far too distracted from work
Far too distracted from work


Joined: 23 Nov 13
Location: South Devon
Online Status: Offline
Posts: 207
Post Options Post Options   Quote Riv Quote  Post ReplyReply Direct Link To This Post Posted: 19 Sep 18 at 10:13am
Read this thread from sailing anarchy:

http://forums.sailinganarchy.com/index.php?/topic/50081-laser-masts/
Now proud owner of Mistral Div II prototype board
Back to Top
423zero View Drop Down
Really should get out more
Really should get out more


Joined: 08 Jan 15
Location: United Kingdom
Online Status: Offline
Posts: 1541
Post Options Post Options   Quote 423zero Quote  Post ReplyReply Direct Link To This Post Posted: 19 Sep 18 at 8:22pm
Reccomended grades

Aluminium 5000 series alloys (5083, 5086)
Aluminium 6000 series alloys (6061T5/T6, 6082T5/T6)
Back to Top
piglet View Drop Down
Far too distracted from work
Far too distracted from work


Joined: 04 Jan 07
Online Status: Offline
Posts: 473
Post Options Post Options   Quote piglet Quote  Post ReplyReply Direct Link To This Post Posted: 21 Sep 18 at 10:34am
We did this for Laser top sections years ago.
Managed to get some tube through Blackburn metals:
6082 T6 2"x14SWGx6.7m
But it wasn't anodised and the 6.7m length didn't work out for the 3.7m top section.
More hassle than it was worth.

On the other hand I have found many practical applications for busted top sections, including a Miracle boom and squirrel proof dove cot posts.
