Hi, everyone, my name is Julie and quite recently I bought a 38ft yacht. Having never sailed I have booked myself on some courses but need advice.

The boat i bought has only been used for accommodation for the last eight years and has been hooked up to mains electricity. It has no batteries and a wind generator that is not working.

The boat is going to have some work done on it in September and I need to decide what I need to put in, so need help. Been told I need solar panels, also been advice to buy a tow generator?

Any of you have radar, is it worth 1000?
Back to Top
Mister Nick View Drop Down
Far too distracted from work
Far too distracted from work
Avatar

Joined: 01 Aug 09
Location: United Kingdom
Online Status: Offline
Posts: 389
Post Options Post Options   Quote Mister Nick Quote  Post ReplyReply Direct Link To This Post Posted: 12 Aug 15 at 7:15pm
Where is the boat going to be kept, and what kind of sailing are you planning to do?

I'd be inclined to install a service battery and an engine battery and then set the boat up around that. If the boat is going to live in a marina then you may as well take advantage of the fact that you can hook up to the shore power and keep the batteries charged that way. Bear in mind that the engine should charge the batteries up too when it's running.

A radar probably isn't going to be that useful to you. I'd buy a decent chartplotter, plus instruments to measure speed through the water, depth and heading. Some kind of instrument that measures GPS speed and heading can also be useful to give you more of an idea about the tides and currents that you're dealing with. If you've got all of that then you're pretty well covered for the majority of the sailing that you'll do.

It might be worth doing your courses before you rush into having the boat rewired and buying new instruments; you'll have a much better idea of what you need and what is actually useful that way. Try and get some cruising experience with other people too, you'll learn loads about sailing and you'll also be able to see how yachts are normally set up, not just from an electrical point of view but also in terms of rigging, plumbing etc.
Back to Top
Van Mentz View Drop Down
Newbie
Newbie


Joined: 27 Aug 12
Location: West Wight
Online Status: Offline
Posts: 32
Post Options Post Options   Quote Van Mentz Quote  Post ReplyReply Direct Link To This Post Posted: 13 Aug 15 at 6:39am
Good advice from Mr Nick.

My ethos is to install the minimum level of electrical equipment otherwise you will become its servant rather than the other way round - if you haven't got it - it can't go wrong.
Back to Top
NEWPAGE View Drop Down
Newbie
Newbie


Joined: 10 Aug 15
Location: Cheshire
Online Status: Offline
Posts: 7
Post Options Post Options   Quote NEWPAGE Quote  Post ReplyReply Direct Link To This Post Posted: 13 Aug 15 at 3:18pm
Hi and thank you Mr Nick

The GPS I can use a phone/tablet, can't I?
Back to Top
Mister Nick View Drop Down
Far too distracted from work
Far too distracted from work
Avatar

Joined: 01 Aug 09
Location: United Kingdom
Online Status: Offline
Posts: 389
Post Options Post Options   Quote Mister Nick Quote  Post ReplyReply Direct Link To This Post Posted: 13 Aug 15 at 6:40pm
Originally posted by NEWPAGE

Hi and thank you Mr Nick

The GPS I can use a phone/tablet, can't I?

There's no reason why not, depending on the device it might not be as accurate as a proper instrument but it should do the job. Most chartplotters will give you all the neccesary GPS info anyway, so you might not even need to go down that route.
Back to Top
MerlinMags View Drop Down
Admin Group
Admin Group
Avatar

Joined: 19 Mar 04
Location: UK, Guildford
Online Status: Offline
Posts: 544
Post Options Post Options   Quote MerlinMags Quote  Post ReplyReply Direct Link To This Post Posted: 14 Aug 15 at 5:53pm
Originally posted by NEWPAGE

The GPS I can use a phone/tablet, can't I?


If you have a waterproof case, and a backup device should you drop the first one overboard!
Back to Top
NEWPAGE View Drop Down
Newbie
Newbie


Joined: 10 Aug 15
Location: Cheshire
Online Status: Offline
Posts: 7
Post Options Post Options   Quote NEWPAGE Quote  Post ReplyReply Direct Link To This Post Posted: 15 Aug 15 at 12:33am
Thanks!!!

Any one recommend a chart plotter?

Was in North Wales today and looked at a few when I called at a chandlers, but prices varied from 300 to nearly 2000. The sales man dazzled me with tech stuff and suggested a Ray.... (forget the make now) for 600, although as suggested by Mr Nick I will wait until I get my courses out of the way.

Anyone know if rewiring a control panel and navigation lights a big job?

Beginning to wish i bought a boat that was ready to go.
Back to Top
laser193713 View Drop Down
Really should get out more
Really should get out more


Joined: 13 May 09
Location: United Kingdom
Online Status: Offline
Posts: 859
Post Options Post Options   Quote laser193713 Quote  Post ReplyReply Direct Link To This Post Posted: 14 Oct 15 at 4:27pm
On a 38 foot boat the standard set up would be two domestic batteries and an engine start battery. These should be wired onto two separate circuits so that the engine battery isn't accidentally discharged by the fridge, lights, chart plotter etc.

A good safe bet for an instrument system would be Raymarine. Their E7 chart plotter is very good and affordable and can be linked in well with the i50 instruments and Ray50 radio. I would stick with a chart plotter with built in GPS, ideally an AIS receiver (no need to transmit really unless you have money to burn) a VHF radio, and a speed and depth instrument with a Airmar Triducer is a safe bet depending on hull shape. For compass just stick with an analogue one. A later upgrade could be an electronic compass unit to give some more data to the chart plotter. Another upgrade would be a wind instrument. The final bit of luxury would be an autohelm system. The Raymarine system is the most simple to use and with the best customer support in my experience.
Back to Top
wavestimulus View Drop Down
Newbie
Newbie
Avatar

Joined: 20 Sep 15
Online Status: Offline
Posts: 1
Post Options Post Options   Quote wavestimulus Quote  Post ReplyReply Direct Link To This Post Posted: 08 Apr 16 at 9:27pm
As a side note to avoid the engine start battery and have one circuit.

May be this is off-topics, or may discussed somewhere else (couldn't find it),
but on the subject of electric motor (to replace a very old diesel), was
watching on youtube Sailing Uma, installation of their DIY electric engine.
Seems to me they have studied their project.

I understand that still expensive and not yet same performance as diesel.
But what is the current status? Any experienced sailor with electric engine?
especially on the DIY level ?
